What Is A Fire-Rated Access Panel?

A fire-rated access panel is a pre-fabricated door and frame that is an essential component in buildings where fire safety is a priority. They provide access to vital systems such as plumbing, electrical wiring and HVAC components, while offering fire resistance to help contain flames in the event of a fire.

In this blog, we will explore fire-rated access panels, identify where they can be installed and why FlipFix access panels are a great choice for quick and easy installation.

Types of fire-rated access panels

Where can fire-rated access panels be installed?

Access panels that are fire-rated are commonly installed in commercial, industrial and residential buildings to ensure compliance with fire safety regulations and building codes.

They are strategically installed in wall cavities or ceiling voids that house essential services, ensuring convenient access for regular maintenance and inspection.

Can fire-rated access panels be painted?

The plasterboard door beaded frame design is the only access panel that can be plastered and painted over in your desired colour.

While other fire-resistant access panels can be painted, it's not recommended as the paint may peel, leading to an unsatisfactory finish. For a specific colour, a bespoke RAL option is recommended.

Why choose FlipFix fire-rated access panels?

Flipfix is one of the UK's leading manufacturers of access panels, known for offering innovative solutions that save up to 80% on labour time and reduce material costs.

At Fire Seals Direct, we stock a range of 1-hour fire-rated access panels from Flipfix in popular sizes and styles to suit your project needs.

Some of the key benefits include:

• Pre-fitted with a unique FlipFix fixing system – Ensures a secure fit in minutes by clamping straight onto plasterboard without the need for fixings.
• Quick fitting – They come with a pop-out template for accurate measuring and have a 4 minute fitting time.
• Seamless finish – Designed to blend into drywall for a discreet appearance.
• Multiple sizes available – Suitable for different access requirements and come in a wide range of sizes.
• Long-lasting durability – Made from high-quality materials for longevity and minimal maintenance.
• Bespoke orders – Flipfix offers custom panels in bespoke sizes and RAL colours, with fast lead times thanks to UK-based manufacturing. 2-hour fire-rated access panels are also available on request.
• Fire testing – Tested for wall and ceiling applications in line with British Standards including BS EN 1634-1: 2014 and BS EN 1363-1: 2012.

You can find, review and download all test evidence documents on each of our product pages.

How to install fire-rated access panels?

Installing a fire-rated access panel doesn’t have to be complicated. With FlipFix, the process is quick, simple and requires minimal tools to install fire-rated access panels in ceilings and walls.

Step-by-step installation guide:

1. Use the pop-out template from the packaging to mark out the area on the wall or ceiling.
2. Cut the area with a drywall saw to form your opening.
3. Position the fixing clamps so they are facing the drywall and place the panel into the aperture, ensuring it sits flush with the surface.
4. Using a screwdriver or drill, tighten the screws until the clamps are firmly secured to the plasterboard.

Follow these additional steps when installing a plasterboard beaded frame panel:

5. Apply Lorient Intumescent Sealant on both faces of the frame, nominally 5mm wide sealing to the supporting construction.
6. Plaster over the panel face and frame for a seamless finish, leaving only the lock visible. The door can be easily removed if needed.
7. Once plastered over, you are able to decorate to match the wall/ceiling.

Want to see just how easy it is? Watch the step-by-step installation video below:

How FireSealsDirect can help

As a family business with 50 years of experience in fire safety, we offer a wide range of products from leading brands to help keep your building compliant. From fire door hardware to fire stopping solutions, we have everything you need—and if you're looking for bespoke items, our team is here to help.

Our expert customer care team is available to assist with any questions. Contact us via live chat, email [email protected] or give us a call on 02920 857 959.

For helpful guides on fire legislation, installation instructions and more, visit our Advice Centre.
