Zoo Hardware Vier Din Euro Sashlock - Backset 60mm - ZDL7260SS

The Vier Din Euro Sashlock has been tested for use on 30, 60, 90 and 120 minute timber fire doors, and 30, 60, 90, 120 and 240 minute steel fire doors.

For use with Euro Profile Cylinder Lock Barrels.

Must be installed with intumescent lock protection when installing in fire doors.

Features

• 60mm backset
• 90mm case size
• 72mm lock centres
• DIN European standard
• Square profile - 22mm Grade 304 stainless steel forend
• Grade 304 stainless steel latchbolt & deadbolt
• Double throw deadbolt
• Anti-rattle strike
• Grip tight follower
• Supplied with fixing screws

Lock Protection

• For 30 minute fire door applications use 1mm intumescent lock protection
• For 60 minute fire door applications use 2mm intumescent lock protection

Failure to install lock protection will invalidate the Certifire certificate.

Testing

• Tested in accordance to BS EN 12209:2003 Grade 3
• Tested in accordance to BS EN1634-1
• CF850 - Certifire Certificate
• UKCA marked
• CE marked

*Please note: Euro Profile locks & latches are compatible with Euro Cylinders. The size of the cylinder lock barrel required will be determined by the thickness of the door and size of the escutcheons.
