Rutland TS9205 Door Closer Installation Jig - Pull Side

Quantity enquiry

If you would like to order more of this item than we currently have in stock please fill out the form below to make an enquiry with our team.

Back

TS9205 Push Side Door Closer Fitting Jig

13 in stock TS9205 Push Side Door Closer Fitting Jig

Rutland TS9205 Door Closer Installation Jig - Pull Side

A dedicated steel installation template designed for the rapid fitting of Rutland TS.9205 door closers on the pull side (Fig. 1) of the door.

Instant Alignment: Hooks securely over the top corner of the door leaf for immediate, accurate positioning without measuring.
Error-Free Drilling: Features clearly engraved guides for both Right Hand (RH) and Left Hand (LH) setups to prevent costly handing mistakes.
Site Efficiency: Eliminates the need for paper templates, allowing contractors to drill pilot holes for the closer body and shoe in seconds.

Product Code: RUCJ001

Need more than 13?

If you would like to order more of this item than we currently have in stock, please click here and fill in the form that appears to make an enquiry with our team.

Select Jig Version

£66.12 Inc. VAT£55.10 Exc. VAT

EXC VAT INC VAT

- +

Item added to cart successfully. View basket

Orders placed today will be dispatched on Monday**Applies to UK mainland customers only - find out more delivery information

Downloads and data sheets

Datasheet Fitting Instructions

Description

Specifications

FAQs

Description

The Rutland JIG.9205.PL is a precision metal installation template engineered specifically for fitting TS.9205 door closers on the pull side of the door. Designed for professional joiners and contractors, this tool replaces disposable paper templates with a rigid steel guide, ensuring the closer body and arm are positioned correctly every time.

Speed and accuracy are the core benefits of this jig. Unlike the push-side variant which clamps to the stop, the JIG.9205.PL is designed to hook directly over the top corner of the door leaf. This design automatically sets the correct vertical and horizontal alignment for a Figure 1 application. By removing the need to measure down from the head or across from the hinge, you can significantly reduce installation time across large sites.

The jig is clearly laser-engraved with Right Hand (RH) and Left Hand (LH) indicators, along with specific guides for the arm shoe location. This visual clarity ensures that even when working under pressure, the critical geometry between the closer body and the frame is maintained. The result is a smooth-operating fire door installed in a fraction of the standard time.

Model: JIG.9205.PL
Application: Pull Side (Fig. 1)
Compatible Closer: Rutland TS.9205
Mounting Method: Top-corner hook alignment
Handing: Universal (marked for LH and RH)
Material: Metal

This product is designed specifically for the installation of the Rutland TS.9205 Door Closer.

Specs

MPN: JIG.9205.PL
Compatible Closer: Rutland TS.9205
Door Thickness Suitability: 44mm - 54mm
Handing: Universal
Material: Metal
Mounting Method: Top-corner hook alignment
